Forklift Electric
Explore our comprehensive range of forklifts and wheel loaders. Each machine is engineered for performance, durability, and efficiency.
Forklift Electric
B20
Kapasitas Angkat (Kg)
2000
Jarak Pusat Beban (mm)
500
Power
Baterai Lithium
Applicable work conditions
Warehouse
Warehouse
FEATURE
Forklift Listrik B20 menawarkan kombinasi performa, efisiensi energi, dan kenyamanan operasional. Dirancang untuk berbagai aktivitas pengangkatan dan pemindahan material, unit ini
cocok digunakan di gudang, pusat logistik, dan lingkungan industri modern yang mengutamakan efisiensi kerja.
SPESIFIKASI
| Power: Lithium battery | Lift Height: 3000mm |
|---|---|
| Rated lifting capacity: 2000kg | Fork adjustment range: 260-1100mm |
| Load center distance: 500mm | Gantry inclination angle: 5°/10° |
| Operation mode: SIT-ON TYPE | Max. lifting speed (no load): 325mm/s |
| Length (With fork): 3395mm | Max. lifting speed (full load): 250mm/s |
| Length (Without fork): 2310mm | Max. operating speed (no load): 15km/h |
| Width: 1100mm | Max. operating speed (full load): 14km/h |
| Height of non-lifting gantry: 2035mm | Max. gradeability (full load): 15% |
| Height of roof guard: 2020mm | Overall weight: 2718kg |
| Max. height during operation: 4110mm | Number of wheels: 2/2 |
| Wheelbase: 1520mm | Tyre: Inflation |
| Front overhang: 370mm | Front Tyre size: 6.5-10 |
| Rear overhang: 380mm | Rear Tyre size: 5.00-8 |
| Front track width: 904mm | Service Brakes: foot brake |
| Rear track width: 958mm | Parking Brakes: hand brake |
| Ground clearance: 110mm | Drive motor power: 13kw |
| Minimum turning radius: 2100mm | Pump Motor Power: 13kw |
