Forklift Offroad
Y50
Kapasitas Angkat (Kg)
5000
Jarak Pusat Beban (mm)
500
Power
Diesel
Applicable work conditions
Warehouse
Warehouse
FEATURE
Offroad Forklift Y50 adalah Integrated Rough Terrain Forklift generasi terbaru dari Shandong Mingyu Heavy Industry yang dirancang khusus untuk memadukan daya angkat beban berat
industri dengan mobilitas off-road menawarkan saat harus beroperasi di atas lumpur, kerikil, maupun permukaan tanah yang tidak rata dan menanjak.
SPESIFIKASI
| Power: Diesel | Lift Height: 3000mm |
|---|---|
| Rated lifting capacity: 5000kg | Fork adjustment range: / |
| Load center distance: 500mm | Gantry inclination angle: 10/12° |
| Operation mode: RIDE-ON | Max. lifting speed (no load): 450mm/s |
| Length (With fork): 4975mm | Max. lifting speed (full load): 400mm/s |
| Length (Without fork): 3755mm | Max. operating speed (no load): 30km/h |
| Width: 1840mm | Max. operating speed (full load): 28km/h |
| Height of non-lifting gantry: 2535mm | Max. gradeability (full load): 30% |
| Height of roof guard: 2585mm | Overall weight: 7500kg |
| Max. height during operation: 4555mm | Number of wheels: 2/2 |
| Wheelbase: 2250mm | Tyre: Inflation |
| Front overhang: 600mm | Front Tyre size: 16/70-20 |
| Rear overhang: 905mm | Rear Tyre size: 16/70-20 |
| Front track width: 1480mm | Service Brakes: foot brake |
| Rear track width: 1480mm | Parking Brakes: hand brake |
| Ground clearance: 325mm | Engine Power: 36.8kw |
| Minimum turning radius: 4325mm | Speed: 2500r/min |
